How to check a fuse with a multimeter?

Checking a fuse with a multimeter is a simple process that can help you quickly determine whether the fuse is still intact or if it has blown. Here’s a step-by-step guide on how to test a fuse with a multimeter:

1. Tools Needed

A multimeter (digital or analog).
The fuse you want to test.

2. Safety Precautions

Power Off: Ensure the device or circuit is powered off before testing the fuse. A fuse protects the circuit from overcurrent, and testing it while the circuit is live could cause electrical shocks or damage to the multimeter.
Discharge Capacitors: If testing a fuse in a circuit with capacitors, make sure they are fully discharged before testing.

3. Steps to Test a Fuse with a Multimeter

Method 1: Continuity Test (Recommended)

Set the Multimeter:

Turn the multimeter dial to the continuity mode (symbol: ⎓ or a diode symbol). If your multimeter doesn't have a dedicated continuity mode, set it to resistance (Ω) mode instead.

Prepare the Multimeter:

Insert the black probe into the COM terminal (common port).
Insert the red probe into the VΩmA terminal (voltage, resistance, or current measurement port).

Test the Fuse:

If the fuse is good: The multimeter will either beep (in continuity mode) or show a low resistance value (in resistance mode), indicating that the fuse is not broken and the circuit is continuous.
If the fuse is blown: The multimeter will either show no reading, display "OL" (Overload) in resistance mode, or display infinite resistance, indicating that there is no continuity through the fuse (the circuit is open).

Place the probes on both ends of the fuse. Ensure that the multimeter probes make contact with the metal ends (the terminals of the fuse).
Observe the Multimeter Reading:

Method 2: Resistance Measurement

Set the Multimeter to Resistance (Ω):

Turn the dial to the resistance (Ω) mode.

Connect the Multimeter:

Place the black probe in the COM terminal.
Place the red probe in the VΩmA terminal.

Measure the Fuse Resistance:

A good fuse will show a very low resistance (close to 0Ω).
A blown fuse will show infinite resistance (or "OL" if using a digital multimeter).

Touch the probes to the ends of the fuse.
Read the Display:

4. Results Interpretation

Reading	Condition
Continuity Beep / Low Resistance (~0Ω)	Fuse is good.
Infinite Resistance ("OL" or no beep)	Fuse is blown or open.
Resistance > 0Ω but not very low	The fuse may be partially degraded, and should be replaced.

5. Additional Tips

Check the Fuse Type: Some fuses are rated for specific voltage or current limits. Always ensure you replace a blown fuse with one of the same type and rating.
Visual Inspection: Before using the multimeter, also visually inspect the fuse. If it appears to have a melted or burnt wire inside, it's likely blown.
For Small Fuses: If testing a very small fuse, such as a surface-mount fuse, you may need to use the fine-tipped probes for better contact.
Test Multiple Fuses: If testing fuses in a device, check them all to make sure none are faulty.

Conclusion

Testing a fuse with a multimeter is a quick and simple way to check if it's functioning properly. By using the continuity or resistance mode, you can easily determine whether a fuse is blown and in need of replacement.
